TRIDONIC driver LCA 100W 24V one4all SC PRE dimmable

Constant voltage LED driver LCA 24V one4all SC PRE IP20 from TRIDONIC, variable dimming options Thanks to the one4all interface, this driver for 24V LEDs can be controlled via various protocols - DALI, DSI, switchDIM or corridorFUNCTION; it can also be configured via the mains (ready2mains). The slimline LED driver can be used independently or integrated. Typical areas of application are cove lighting, façade accent lighting and indirect ceiling lighting.

- for installation in dry environments - suitable for furniture construction (M/MM mark) - housing with strain relief - dimming range: 1 % to 100 % - lumDATA: luminaire data, energy report, diagnostics and maintenance - ambient temperature during operation: - 25 °C to + 50 °C - control interfaces: one4all (DALI, DSI, switchDIM, corridorFUNCTION), ready2mains (configuration and dimming via mains) - 45° plug-in terminals for connection - complies with standards: EN 55015, EN 61000-3-2, EN 61000-3-3, EN 61347-1, EN 61347-2-13, EN 62384, EN 61547, EN 62386-101/102/103, EN 50172 (suitable for central battery systems), EN 60598-2-22 (suitable for emergency lighting installations)
